| wdt_ID | wdt_created_by | wdt_created_at | wdt_last_edited_by | wdt_last_edited_at | NR katalogowy | d | D | H | H1 | H2 | Śruby | Moment dokręcania (Nm) | Ilość śrub | Śruby do odkręcania | Ilość śrub | Przenoszony moment Mt (Nm) | Przenoszony moment Ta (KN) | Nacisk na wałek Pa (N/mm²) | Nacisk na piastę Pm (N/mm²) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 860 | admindagar | 03/11/2025 07:39 PM | admindagar | 03/11/2025 07:39 PM | KLEE025 | 25 | 55 | 46 | 40 | 32 | M6x35 | 17 | 6 | M6x35 | 3 | 799 | 64 | 314 | 107 |
| 861 | admindagar | 03/11/2025 07:39 PM | admindagar | 03/11/2025 07:39 PM | KLEE028 | 28 | 55 | 46 | 40 | 32 | M6x35 | 17 | 6 | M6x35 | 3 | 895 | 64 | 281 | 107 |
| 862 | admindagar | 03/11/2025 07:39 PM | admindagar | 03/11/2025 07:39 PM | KLEE030 | 30 | 55 | 46 | 40 | 32 | M6x35 | 17 | 6 | M6x35 | 3 | 959 | 64 | 262 | 107 |
| 863 | admindagar | 03/11/2025 07:39 PM | admindagar | 03/11/2025 07:39 PM | KLEE035 | 35 | 60 | 60 | 54 | 44 | M6x45 | 17 | 7 | M6x45 | 3 | 1306 | 75 | 185 | 83 |
| 864 | admindagar | 03/11/2025 07:39 PM | admindagar | 03/11/2025 07:39 PM | KLEE038 | 38 | 75 | 62 | 54 | 44 | M8x50 | 41 | 7 | M8x50 | 3 | 2567 | 135 | 308 | 121 |
| 865 | admindagar | 03/11/2025 07:39 PM | admindagar | 03/11/2025 07:39 PM | KLEE040 | 40 | 75 | 62 | 54 | 44 | M8x50 | 41 | 7 | M8x50 | 3 | 2702 | 135 | 293 | 121 |
| 866 | admindagar | 03/11/2025 07:39 PM | admindagar | 03/11/2025 07:39 PM | KLEE042 | 42 | 75 | 62 | 54 | 44 | M8x50 | 41 | 7 | M8x50 | 3 | 2837 | 135 | 279 | 121 |
| 867 | admindagar | 03/11/2025 07:39 PM | admindagar | 03/11/2025 07:39 PM | KLEE045 | 45 | 75 | 62 | 54 | 44 | M8x50 | 41 | 7 | M8x50 | 3 | 3040 | 135 | 260 | 121 |
| 868 | admindagar | 03/11/2025 07:39 PM | admindagar | 03/11/2025 07:39 PM | KLEE048 | 48 | 80 | 72 | 64 | 56 | M8x55 | 41 | 8 | M8x55 | 4 | 3707 | 154 | 216 | 102 |
| 869 | admindagar | 03/11/2025 07:39 PM | admindagar | 03/11/2025 07:39 PM | KLEE050 | 50 | 80 | 72 | 64 | 56 | M8x55 | 41 | 8 | M8x55 | 4 | 3861 | 154 | 207 | 102 |
| 870 | admindagar | 03/11/2025 07:39 PM | admindagar | 03/11/2025 07:39 PM | KLEE055 | 55 | 85 | 72 | 64 | 56 | M8x55 | 41 | 9 | M8x55 | 4 | 4779 | 174 | 212 | 108 |
| 871 | admindagar | 03/11/2025 07:39 PM | admindagar | 03/11/2025 07:39 PM | KLEE060 | 60 | 90 | 72 | 64 | 56 | M8x55 | 41 | 10 | M8x55 | 4 | 5793 | 193 | 216 | 113 |
| 872 | admindagar | 03/11/2025 07:39 PM | admindagar | 03/11/2025 07:39 PM | KLEE065 | 65 | 95 | 72 | 64 | 56 | M8x55 | 41 | 10 | M8x55 | 4 | 6276 | 193 | 199 | 107 |
| 873 | admindagar | 03/11/2025 07:39 PM | admindagar | 03/11/2025 07:39 PM | KLEE070 | 70 | 110 | 88 | 78 | 70 | M10x60 | 83 | 10 | M10x60 | 4 | 10951 | 313 | 235 | 120 |
| 874 | admindagar | 03/11/2025 07:39 PM | admindagar | 03/11/2025 07:39 PM | KLEE075 | 75 | 115 | 88 | 78 | 70 | M10x60 | 83 | 10 | M10x60 | 4 | 11733 | 313 | 220 | 115 |
| 875 | admindagar | 03/11/2025 07:39 PM | admindagar | 03/11/2025 07:39 PM | KLEE080 | 80 | 120 | 88 | 78 | 70 | M10x60 | 83 | 11 | M10x60 | 4 | 13768 | 344 | 227 | 121 |
| 876 | admindagar | 03/11/2025 07:39 PM | admindagar | 03/11/2025 07:39 PM | KLEE085 | 85 | 125 | 88 | 78 | 70 | M10x60 | 83 | 12 | M10x60 | 5 | 15959 | 376 | 233 | 127 |
| 877 | admindagar | 03/11/2025 07:39 PM | admindagar | 03/11/2025 07:39 PM | KLEE090 | 90 | 130 | 88 | 78 | 70 | M10x60 | 83 | 12 | M10x60 | 5 | 16898 | 376 | 220 | 122 |
| 878 | admindagar | 03/11/2025 07:39 PM | admindagar | 03/11/2025 07:39 PM | KLEE095 | 95 | 135 | 88 | 78 | 70 | M10x60 | 83 | 12 | M10x60 | 5 | 17837 | 376 | 208 | 117 |
| 879 | admindagar | 03/11/2025 07:39 PM | admindagar | 03/11/2025 07:39 PM | KLEE100 | 100 | 145 | 112 | 100 | 90 | M12x80 | 145 | 11 | M12x80 | 4 | 25029 | 501 | 211 | 113 |
| 880 | admindagar | 03/11/2025 07:39 PM | admindagar | 03/11/2025 07:39 PM | KLEE110 | 110 | 155 | 112 | 100 | 90 | M12x80 | 145 | 12 | M12x80 | 5 | 30039 | 546 | 209 | 115 |
| 881 | admindagar | 03/11/2025 07:39 PM | admindagar | 03/11/2025 07:39 PM | KLEE120 | 120 | 165 | 112 | 100 | 90 | M12x80 | 145 | 14 | M12x80 | 6 | 38226 | 637 | 224 | 127 |
| 882 | admindagar | 03/11/2025 07:39 PM | admindagar | 03/11/2025 07:39 PM | KLEE130 | 130 | 180 | 130 | 116 | 104 | M14x90 | 230 | 12 | M14x90 | 5 | 48270 | 743 | 201 | 117 |
| 883 | admindagar | 03/11/2025 07:39 PM | admindagar | 03/11/2025 07:39 PM | KLEE140 | 140 | 190 | 130 | 116 | 104 | M14x90 | 230 | 14 | M14x90 | 7 | 60654 | 866 | 217 | 129 |
| 884 | admindagar | 03/11/2025 07:39 PM | admindagar | 03/11/2025 07:39 PM | KLEE150 | 150 | 200 | 130 | 116 | 104 | M14x90 | 230 | 15 | M14x90 | 7 | 69628 | 928 | 217 | 132 |
